| Availability: | |
|---|---|
|
| |
Module | VIR-II2.9 | VIR-II3.9 | VIR-II4.8 | |
Pixel Pitch | 2.97 mm | 3.91 mm | 4.81mm | |
Brightness | 800-1200nits | 800-1200 nits | 800-1200 nits | |
Refresh Rate | 1920/3840 Hz | 1920/3840 Hz | 1920/3840 Hz | |
Driving Method | 1/21scan | 1/16Scan | 1/16Scan | |
Grey level | 13 bit | 13 bit | 13 bit | |
LED Type | SMD2020 | SMD2020 | SMD2020 | |
IP Grade | IP30/IP30 | IP30/IP30 | IP30/IP30 | |
Power consumption(Max/Average) | 436/144 W/sq.m | 436/144 W/sq.m | 436/144 W/sq.m | |
Cabinet | ||||
Module Size (mm) | 250×250mm | 250×250 mm | 250×250mm | |
Cabinet Size(mm) | 500×500×75 mm 500×1000×75 mm | |||
Cabinet Material | ADC12 | |||
Cabinet weight(kg) | 8 kg/15.5kg | 8 kg/15.5kg | 8 kg/15.5kg | |
Cabinet resolution | 168×168 Pixels | 128×128 Pixels | 104×104 Pixels | |
Pixel density | 112896 Pixels/sq.m | 65536 Pixels/sq.m | 43264 Pixels/sq.m | |
Application environment | ||||
Input AC power voltage | 110V-240V | |||
Working temperature | -20℃~50℃ | |||
Working humidity | 10%-95% | |||
Signal type(with video processor) | AV, S-Video, VGA, DVI, HDMI, SDI, DP | |||
Control distance | cat-5Lan cable:<1000m;single-mode fiber cable:<10kilometer | |||
Module | VIR-II2.9 | VIR-II3.9 | VIR-II4.8 | |
Pixel Pitch | 2.97 mm | 3.91 mm | 4.81mm | |
Brightness | 800-1200nits | 800-1200 nits | 800-1200 nits | |
Refresh Rate | 1920/3840 Hz | 1920/3840 Hz | 1920/3840 Hz | |
Driving Method | 1/21scan | 1/16Scan | 1/16Scan | |
Grey level | 13 bit | 13 bit | 13 bit | |
LED Type | SMD2020 | SMD2020 | SMD2020 | |
IP Grade | IP30/IP30 | IP30/IP30 | IP30/IP30 | |
Power consumption(Max/Average) | 436/144 W/sq.m | 436/144 W/sq.m | 436/144 W/sq.m | |
Cabinet | ||||
Module Size (mm) | 250×250mm | 250×250 mm | 250×250mm | |
Cabinet Size(mm) | 500×500×75 mm 500×1000×75 mm | |||
Cabinet Material | ADC12 | |||
Cabinet weight(kg) | 8 kg/15.5kg | 8 kg/15.5kg | 8 kg/15.5kg | |
Cabinet resolution | 168×168 Pixels | 128×128 Pixels | 104×104 Pixels | |
Pixel density | 112896 Pixels/sq.m | 65536 Pixels/sq.m | 43264 Pixels/sq.m | |
Application environment | ||||
Input AC power voltage | 110V-240V | |||
Working temperature | -20℃~50℃ | |||
Working humidity | 10%-95% | |||
Signal type(with video processor) | AV, S-Video, VGA, DVI, HDMI, SDI, DP | |||
Control distance | cat-5Lan cable:<1000m;single-mode fiber cable:<10kilometer | |||
