VOT Series | ||||
Pixel Pitch(mm) | 3.91-7.81mm | 7.8-7.8mm | 5.2-10.42mm | 10.42-10.42mm |
product type | Front-emitting | |||
Pixel Density(dot/m2) | 32768 | 16384 | 18432 | 9216 |
Cabinet Resolution(px*px) | 256*64 | 128*64 | 192*96 | 96*96 |
LED type | custom-made | |||
Cabinet Sie(mm*mm*mm) | 1000mm*500mm | |||
Cabinet Weight | 7.5KG | |||
Application | indoor | |||
Brightness | 1200-5500nits | |||
Transparency | 87% | 85% | 87% | 87% |
Grey Scale(bit) | 16bit | |||
Refresh Rate(hz) | 3840HZ | |||
Max Power Consumption(w/sqm) | 1000 | 800 | 800 | 800 |
Averaqe Power Consumption(w/sqm) | 340 | 260 | 260 | 260 |
input Voltage(V) | 110-220VAC,50-60HZ | |||
ingress Protection(front/rear) | IP43/IP65 |
VOT Series | ||||
Pixel Pitch(mm) | 3.91-7.81mm | 7.8-7.8mm | 5.2-10.42mm | 10.42-10.42mm |
product type | Front-emitting | |||
Pixel Density(dot/m2) | 32768 | 16384 | 18432 | 9216 |
Cabinet Resolution(px*px) | 256*64 | 128*64 | 192*96 | 96*96 |
LED type | custom-made | |||
Cabinet Sie(mm*mm*mm) | 1000mm*500mm | |||
Cabinet Weight | 7.5KG | |||
Application | indoor | |||
Brightness | 1200-5500nits | |||
Transparency | 87% | 85% | 87% | 87% |
Grey Scale(bit) | 16bit | |||
Refresh Rate(hz) | 3840HZ | |||
Max Power Consumption(w/sqm) | 1000 | 800 | 800 | 800 |
Averaqe Power Consumption(w/sqm) | 340 | 260 | 260 | 260 |
input Voltage(V) | 110-220VAC,50-60HZ | |||
ingress Protection(front/rear) | IP43/IP65 |
