Stadium sports LED Display

Physical Pitch

8mm

10mm

16mm

Pixel Configuration

SMD3535

SMD3535

SMD3535

Pixel Density

15625 pixels/m²

10000 pixels/m²

3906 pixels/m²

Module Dimensions (W× H) (mm)

256X256

320X320

256X128

Panel Dimensions (mm)

1280X768X187

1280X960X187

1280X896X187

NO.of Modules Per Panel (W × H)

5X3

4X3

5X7

Physical Resolution of Module ( W× H)

32x32

32X32

32X8

Physical Resolution of Panel ( W× H)

160X96

128X96

160X56

Weight (m²)

70/50

70/50

70/50

Panel Material

Steel / Aluminum

Steel / Aluminum

Steel / Aluminum

Gray Scale

16 bit

16 bit

16 bit

Colours

281 trillion

281 trillion

281 trillion

Contrast Ratio

2000:1

2000:1

2000:1

Average Power Consumption

360W/m²

360W/m²

360W/m²

Max Power Consumption

900W/m²

900W/m²

900W/m²

Refresh Rate

>1920 Hz

>1920 Hz

>1920 Hz

Brightness

>6500 nits

>6500 nits

>6500 nits

Horizontal Viewing Angle

160°

160°

160°

Vertical Viewing angle

140°

140°

140°

Expected Lifetime

100,000 Hrs

100,000 Hrs

100,000 Hrs

Servicing

Front / Rear

Front / Rear

Front / Rear

IP Rating (Front/Rear)

IP65 / IP54

IP65 / IP54

IP65 / IP54

Operating Temperature

-20~50℃/10~90℃

-20~50℃/10~90℃

-20~50℃/10~90℃

Storage  Temperature

-20~50℃/10~90℃

-20~50℃/10~90℃

-20~50℃/10~90℃

Scan Method

1/4 Scan

1/2 Scan

Static Scan
